BP1000nm Bandpass Filter | 10nm FWHM, OD3+ Broad Blocking
The OPTOStokes BP1000 is a precision NIR bandpass filter engineered for accurate spectral selection at 1000nm. With over 90% peak transmission at the central wavelength, a narrow 10nm full-width at half-maximum (FWHM), and high optical density blocking across the 350–1100nm range, this filter delivers reliable performance for demanding near-infrared optical systems. It is fabricated using advanced thin-film coating technology on high-quality optical substrates, ensuring consistent spectral response, low environmental drift, and long-term durability for both industrial and laboratory applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Central Wavelength (CWL) | 1000 ± 2 nm @ Transmission > 90% |
| Full Width at Half Maximum (FWHM) | 10 ± 2 nm |
| Peak Transmission | > 90% at 1000 nm |
| Blocking Range & Optical Density | 350 – 1100 nm @ OD > 3 |
| Angle of Incidence (AOI) | 0 degrees |
Typical Applications
This 1000nm bandpass filter is optimized for a broad range of near-infrared use cases. It is widely deployed in NIR spectroscopy, laser line isolation, machine vision inspection, analytical instrumentation, and industrial optical assemblies. Its precise spectral characteristics make it suitable for OEM system integration, prototype validation, and replacement part requirements in biomedical imaging and laser measurement setups.
Customization & Service Support
OPTOStokes maintains an extensive in-stock selection of standard bandpass filters for fast turnaround, while also providing full customization services to match unique project requirements. We support custom dimensions, substrate materials, and mounting ring options, with available shapes including round, square, and custom profiles. All products are manufactured to world-class precision standards, with reliable lead times and rigorous quality control to ensure consistent performance across every production batch.
Engineering Support & Inquiry
Sourcing precision optical components often presents challenges: extended lead times for custom configurations, inconsistent coating quality, and limited technical support for complex system integration. At OPTOStokes, we address these pain points with responsive engineering consultation, flexible production capabilities, and a strict commitment to on-time delivery. Whether you need off-the-shelf units for rapid prototyping or fully customized solutions for high-volume OEM production, our technical team is ready to assist. Contact us at sales@optofilters.com to discuss your project requirements or request a detailed quotation.
Tags: narrow bandpass laser optics NIR filter spectroscopy filter optical density 1000nm bandpass filter
