In the demanding field of multi-channel fluorescence microscopy and advanced instrumentation, precision is non-negotiable. The OPTOStokes 555nm, 655nm, and 835nm Triple Bandpass Filter is engineered to simultaneously capture three distinct spectral bands—Green, Red, and Near-Infrared (NIR)—with exceptional clarity. By enabling the detection of multiple fluorophores or laser lines without the need for mechanical filter wheels, this component significantly enhances system speed and data throughput.
Designed for R&D engineers and system integrators requiring high signal-to-noise ratios, this filter utilizes advanced hard-coating technology. It delivers average transmission rates greater than 90 percent across all three passbands while maintaining deep blocking (transmission less than 1 percent) in the out-of-band regions from 350nm to 1050nm. This ensures that crosstalk is minimized, making it an ideal solution for complex imaging setups and biomedical applications.
Technical Specifications
The following table details the optical performance and physical parameters of this triple-band component. All specifications are verified to meet world-class quality standards.
| Parameter | Specification |
|---|---|
| Center Wavelengths (CWL) | 555nm ±2nm, 655nm ±2nm, 835nm ±2nm |
| Full Width at Half Maximum (FWHM) | Band 1: 20nm ±2nm Band 2: 20nm ±2nm Band 3: 30nm ±2nm |
| Transmission Bands | 550-560nm (Tave > 90%) 650-670nm (Tave > 90%) 835-845nm (Tave > 90%) |
| Blocking Range | 350-1050nm (T < 1% outside passbands) |
| Angle of Incidence (AOI) | 0 degrees |
| Surface Quality | 60/40 Scratch-Dig or better |
Typical Applications
This triple bandpass filter is versatile and suited for various high-precision environments. Key applications include:
- Multi-Channel Fluorescence Microscopy: Ideal for simultaneous visualization of multiple targets, compatible with standard dyes and NIR imaging markers.
- Flow Cytometry: precise wavelength separation for sorting and analysis.
- Laser Line Cleaning: Filtering specific excitation lines in multi-laser systems.
- Biomedical Instrumentation: Used in DNA sequencing and PCR devices requiring distinct separation of green, red, and IR signals.
Customization & Manufacturing Excellence
At OPTOStokes, we understand that standard off-the-shelf sizes do not fit every optical design. We offer comprehensive customization services to meet your specific integration requirements.
- Dimensions: Available in standard round sizes (e.g., 12.5mm, 25mm) or custom squares and rectangles.
- Substrates: High-quality fused silica or BK7 equivalent glass options.
- Mounting: We provide bare filters or mounted options in black anodized aluminum rings for easy system integration.
Our manufacturing process leverages state-of-the-art coating technologies to ensure durability and environmental stability. As a dedicated custom optical filter provider, we guarantee consistent batch-to-batch performance.
Ready to Optimize Your Optical System?
Sourcing reliable multi-band optics with short lead times can be a challenge. OPTOStokes bridges this gap with an extensive in-stock selection and rapid prototyping capabilities. Whether you need a single prototype for validation or volume production for your instrument, our engineering team is ready to assist.
Contact us today to discuss your specifications or request a quote.
